Built for hunters and competitors, where split-second decisions make or break success. Talon® HD 10K puts the Vortex’s top-tier glass, extreme-range performance, and real-time ballistic data in one tool you can count on. Run it solo or pair with Vortex Relay™ devices for seamless data flow across your setup. From spotting your target to taking the shot, Talon® HD keeps you fast and focused – no matter the distance.
SpecificationsMagnification: 12xObjective Lens Diameter: 50 mmEye Relief: 18.5mmAngular Field of View: 5.2°Linear Field of View: 272′ @ 1000 yds.Range Reflective (yards): Up to 10,000 yds.Range Tree (yards): Up to 4200 yds.Range Deer (yards): Up to 2600 yds.Min Range: 10 yds.Height: 7.2″Width: 5.6″Weight: 46.8 oz.
Feature Tech
Ranging Modes
- Line of Sight (LOS): Displays the actual line of sight range.
- Horizontal Component Distance (HCD): Displays the slope angle compensated distance to the target.
- Ballistics (BAL): Displays the actual line of sight range and wind/drop solution.
- SCAN Feature: Displays continuous distance readings while panning across a landscape.
Target Modes
- Normal Mode: The standard mode providing the target’s range with the strongest range result. Recommended for most situations.
- First Mode: Displays the closest distance when ranging. Ideal for ranging a smaller target in front of other larger or more reflective objects.
- Last Mode: Displays the farthest distance when ranging. Ideal for ranging a specific target behind a group of objects like brush, trees, rocks, etc.
- Extended Laser Range (ELR) Mode: Ideal for ranging targets at extreme distances. A slightly longer response time allows greatly for extended range distances.
- Rain/Fog Mode: Ideal for ranging in adverse conditions, such as rain, snow, fog, or dust. Helps the rangefinder return accurate readings despite poor visibility.
FEATURES
- 10,000-Yard Capability: For ranging shots, planning stages and stalks.
- HD Optical System: Premium glass and optical technology for long-range clarity.
- In-Display Wind/Drop Solutions: Provided by integrated GeoBallistics® Solver.
- Active Matrix Red OLED Display: Intuitive, customizable, auto-leveling.
- Customizable Ballistic Profiles: Use presets or load your own for any shooting setup.
- On-Board Environmental Sensors: Real-time temperature, pressure, humidity, compass bearing, and inclination.
- Wind Bearing Capture Mode: Lock in wind speed and direction for accurate shots.
- Vortex Relay™ Connectivity: Connects to share real-time ballistic, environmental, and rifle-specific data across a suite of devices.
- Integrated GeoBallistics® Solver: Equipped with the accurate GeoBallistics® Solver backed by a full, up-to-date bullet library.
- Built-in Range Card Generator: Ability to create and save up to ten range cards with drop and wind corrections.
- XR™ Plus Lens Coatings: Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.
- Adjustable Eyecups: Twist up and down for comfortable viewing with or without eyeglasses.
- Center Focus Wheel: Adjusts the focus of both binocular barrels at the same time.
- Locking Diopters: Adjusts for differences in a user’s eyes.
- ArmorTek®: Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
- Rubber Armor: Provides a secure, non-slip grip, and a durable external protection.
- Nitrogen Gas Purged: Gas purged and O-ring sealed for superior fogproof and waterproof performance in the most extreme conditions.
- Waterproof: Designed to withstand harsh weather conditions.
- Fogproof: Designed to withstand a wide range of temperatures.
- Shockproof: Designed to withstand the highest levels of impact.
- Tripod Adaptable: Allowing use on a tripod or car window mount. Tripod adapter may be required.
